602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles

Brand Name: XL
Model Number: 602540
Place of Origin: Guangdong,China
Minimum Order Quantity: 100 pieces
Price: $1.15-1.35 / piece

Product Details

Max Load Quantity(cells): 8 Cycle Life: 500 Cycles, 500 Times
Dimension (L*W*H): 6mm*25mm*40mm(0.24in*0.98in*1.57in) Application: Toys, Power Tools, Home Appliances, Consumer Electronics, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
Weight: 13g(0.46oz) Operating Temperature(℃): -10~55
Cathode Materials: LiCoO2 Type: Lipo Battery
Specifications: 602540 Product Name: Lipo Battery
Capacity: 650mah Voltage: 3.7v
Size: 6mm*25mm*40mm Temperature: -20~60
Warranty: 12Months Scope Of Use: Consumer Electronics, Digital Products, Beauty Equipment,etc.

Product Description

Product Description
No. Item Specifications Remak
1. Specifications(602540) capacity:650mAh 0.2C Rate discharge after standard charge
2. voltage 3.7V Mean operation voltage during standard
3. Voltage at end of discharge 2.75V Discharge cut-off voltage
4. Charging cutoff voltage 4.2V
5. Impedance ≤100mΩ 3.7v 650mah lipo battery
6. Standard charging Constant current 0.2C
Constant voltage 8.4V
Cut-off current≤0.01C
7. Standard discharge Constant current 0.2C
End voltage 6V
8. Fast charge Constant current 0.5C
Constant voltage 8.4V
Cut-off current≤0.02C

9.

 Fast discharge Constant current 0.5C
End voltage 2.75V
10. Maximum continuous discharge current 1.0C
11. Operation Charge: 0~45°C 80±25%R.H
Temperature range Discharge: -20~85°C
12. Cycle life 500times
13. Storage temperature -20 ~ 45°C
14. Weight 13g
15. Dimension(mm) size 6mm*25mm*40mm

 602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 0602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 2

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 4

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 6

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 8

Range of application

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 10602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 12

Connector

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 14

Reasons for choosing

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 16602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 18

Certifications

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 20

Company Information

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 22602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 24602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 26

Packaging & Shipping

 602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 28

FAQ

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 30

602540 High Temperature 3.7v 650mah XL Brand Small Size 6x25x40mm PCB Lithium Ion Battery with 500 Cycles 32

Product Highlights

Product Description No. Item Specifications Remak 1. Specifications(602540) capacity:650mAh 0.2C Rate discharge after standard charge 2. voltage 3.7V Mean operation voltage during standard 3. Voltage at end of discharge 2.75V Discharge cut-off voltage 4. Charging cutoff voltage 4.2V 5. Impedance ...
