| Application: | Toys, Power Tools, Home Appliances, Consumer Electronics, Electric Bicycles/Scooters, Electric Folklifts, Electric Vehicles, Electric Wheelchairs, Electric Power Systems, Uninterruptible Power Supplies | Weight: | 155g(5.47oz) |
|---|---|---|---|
| Electric Energy: | 27.75 Wh | Specifications: | 18650 |
| Product Name: | Polymer Lithium Battery | Capacity: | 2500mah |
| Voltage: | 12v | Size: | 18mm*65mm |
| Temperature: | -20~60 | Cycle Life: | 500 Times |
| Warranty: | 12Months | OEM/ODM: | Yes |
| Scope Of Use: | Electronics,Portable Source,toys,humidifier |
| No. | Item | Specifications | Remak |
| 1. | Specifications(18650) | capacity:2500mAh | 0.2C Rate discharge after standard charge |
| 2. | voltage | 12V | Mean operation voltage during standard |
| 3. | Voltage at end of discharge | 9.0V | Discharge cut-off voltage |
| 4. | Charging cutoff voltage | 12.6V | |
| 5. | Impedance | ≤100mΩ | 11.1v 2500mah lipo battery |
| 6. | Standard charging | Constant current 0.2C | |
| Constant voltage 12.6V | |||
| Cut-off current≤0.01C | |||
| 7. | Standard discharge | Constant current 0.2C | |
| End voltage 9V | |||
| 8. | Fast charge | Constant current 0.5C | |
| Constant voltage 12.6V | |||
| Cut-off current≤0.02C | |||
|
9. |
Fast discharge | Constant current 0.5C | |
| End voltage 9V | |||
| 10. | Maximum continuous discharge current | 1.0C | |
| 11. | Operation | Charge: 0~45°C | 60±25%R.H |
| Temperature range | Discharge: -20~60°C | ||
| 12. | Cycle life | 500times | |
| 13. | Storage temperature | -20 ~ 45°C | |
| 14. | Weight | 155g | |
| 15. | Dimension(mm) | size | 18mm*65mm |
![]()
![]()
![]()
![]()
![]()
1.We not only supply lithium batteries, but also provide customers with various solutions.
2.High capacity and high density lithium ion battery.
3.Stable battery performance and high utilization rate.
4.Green environmental protection materials, safe and pollution-free.
5.Battery short circuit protection, safe to use.
6.Factory price.
7.Models complete, can be customized according to customer requirements.
![]()
![]()
![]()
![]()
