| Application: | Toys, Power Tools, Home Appliances, Consumer Electronics, Electric Folklifts, Electric Wheelchairs, Electric Power Systems, Uninterruptible Power Supplies | Weight: | 93g |
|---|---|---|---|
| Type: | Polymer | Specifications: | 193765 |
| Capacity: | 5300mah | Voltage: | 3.7v |
| Discharge Current: | 1~3C | Size: | H7mm*W30mm*L48mm |
| Temperature: | -40~60 | Cycle Life: | 1000 Times |
| Warranty: | 24Months, 3 Months ~ 1 Year | OEM/ODM: | Yes |
| Battery Size: | 19*37*65mm |
Battery type | High temperature battery |
Moder | 193765 |
Size | 19mm*37mm*65mm |
Voltage | 3.7v |
Capacity | 5300mah |
Temperature | -40~60°C |
No. | Item | Specifications | Remak |
1. | Specifications(193765) | capacity:5300mAh | 0.2C Rate discharge after standard charge |
2. | Naminal voltage | 3.65v | Mean operation voltage during standard |
3. | Voltage at end of discharge | 2.75V | Discharge cut-off voltage |
4. | Charging cutoff voltage | 4.2V | |
5. | Impedance | ≤20mΩ | 5300mah lipo battery |
6. | Standard charging | Constant current 0.2C | |
Constant voltage 4.2V | |||
Cut-off current≤0.01C | |||
7. | Constant current 0.2C | ||
End voltage 2.75V | |||
8. | Constant current 0.5C | ||
Constant voltage 4.2V | |||
Cut-off current≤0.02C | |||
9. | Constant current 0.5C | ||
End voltage 2.75V | |||
10. | Maximum continuous discharge current | 3C | |
11. | Temperature range | Discharge: -40~60°C | |
12. | Storage temperature | -20 ~ 45°C | |
13. | Weight | 93g |
